Key Features

• Max 20fps@5MP
• HD and SD output switchable
• 3.6mm fixed lens
• IR Length 20m, Smart IR
• IP67, DC12V

Features

• Image Sensor : 1/2.7” CMOS
• Lens : 3.6mm horizontal field of view: 87.5° , 6mm horizontal field of view: 56°
• Iris : Fixed iris
• Angle of View (H) : 87.5°
• Day/Night : Auto (ICR) / Manual
• Shutter Speed : PAL : 1/25~1/100000s
• Min.Illumination : 0.04Lux/F2.0, 0Lux IR on
• IR : Up to 20m (66feet)
• S/N : More than 65dB
• WDR : DWDR
• AWB(Auto White Balance) : Auto / Manual
• Digital Zoom : 16x
• Noise Reduction : 2D

Specifications

• Frame Rate : 20fps@5MP, 25/30fps @4MP, 25/30@1080P
• HLC : Supported
• BLC : Supported
• OSD : Multi-language
• Video Output : 1-channel BNC high definition video output / CVBS video output (Can switch) Day/Night
• Storage Conditions : -40°C~+60°C (-40°F~+140°F)/ Lessthan90%RH

Power Features

• Power : 12V DC±25%
• Power Consumption : Max 2.8W (12V DC, IR on)
• Working Temperature : -40°C~+60°C (-40°F~+140°F)
• Working Humidity : Less than 90%RH

Dimensions & Weight

• Dimension : Φ85.4mm × 69.1mm (Φ3.36"×2.72")
• Weight : 0.11kg (0.24lb)
