Key Features:

• Max 20fps@5MP

• HD and SD output switchable

• 3.6mm fixed lens / DC12V

• IR Length: 20m, Smart IR


Features:

• Image Sensor: 1/2.7" CMOS

• Lens: 2.8mm (Horizontal Field of View: 107°), 3.6mm (Horizontal Field of View: 89.9°)

• Iris: Fixed iris

• Angle of View (H): 89.9°

• Day/Night: Auto (ICR) / Manual

• Shutter Speed: PAL: 1/25~1/100000s

• Minimum Illumination: 0.04Lux/F2.0, 0Lux IR on

• IR: Up to 20m (66 feet)

• S/N: More than 65dB

• WDR: DWDR

• AWB (Auto White Balance): Auto / Manual

• Digital Zoom: 16x

• Noise Reduction: 2D


Specifications:

• Frame Rate: 20fps@5MP, 25/30fps @4MP, 25/30@1080P

• HLC: Supported

• BLC: Supported

• OSD: Multi-language

• Video Output: 1-channel BNC high-definition video output / CVBS video output (Can switch) Day/Night

• Storage Conditions: -40°C~+60°C (-40°F~+140°F) / Less than 90%RH


Power Features:

• Power: 12V DC±25% Surge Protection

• Power Consumption: Max 2.8W (12V DC, IR on)

• Working Temperature: -40°C~+60°C (-40°F~+140°F)

• Working Humidity: Less than 90%RH


Dimensions & Weight:

• Dimension: Φ85.4mm × 69.1mm (Φ3.36" × 2.72")

• Weight: 0.11kg (0.24lb)
