Features:

The Cooper Series offers simple and highly cost-effective HDCVI solutions. It provides 24/7 reliable monitoring with high-quality image performance, saving costs on both material and labor force. Designed and built to the specific standards of Dahua.

Specifications:

• Pixel: 2 MP
• Image Sensor: 2MP CMOS
• Max. Resolution: 1920 (H) × 1080 (V)
• Lens Type: Fixed-focal
• Field of View: 2.8 mm: H: 100°, V: 53°, D: 120°; 3.6 mm: H: 82°, V: 42°, D: 98°; 6 mm: H: 53°, V: 30°, D: 60°
• Resolution: 1080p (1920 × 1080); 720p (1280 × 720); 960H (960 × 576/960 × 480)
• Day/Night: Auto(ICR)/Color/B/W
• BLC: BLC; HLC; DWDR
• WDR: DWDR
• White Balance: Auto; Area white balance
• Gain Control: Auto/Manual
• Noise Reduction: 2D NR
• Privacy Masking: Off/On (8 areas, rectangle)

Power Features:

• Power Supply: 12 VDC ± 30%
• Power Consumption: Max. 2.3 W (12 VDC, IR on)

Dimensions & Weight:

• Product Dimensions: Φ85.4 mm × 68.8 mm (Φ3.36" × 2.71")
• Packaging Dimensions: 109 mm × 109 mm × 85 mm (4.29" × 4.29" × 3.35")
• Net Weight: 0.09 kg (0.20 lb)
• Gross Weight: 0.13 kg (0.29 lb)
