Features

The Cooper Series offers simple and highly cost-effective HDCVI solutions. It provides 24/7 reliable monitoring with high-quality image performance, saving cost on both material and labor force. It is also designed and built to the specific standards of Dahua.

• Max. 30 fps@1080p
• CVI/CVBS/AHD/TVI switchable
• 3.6 mm fixed lens (2.8 mm, 6 mm optional)
• Max. IR length 20 m, Smart IR
• IP67,12 VDC

 Specifications

• Pixel : 2 MP
• Image Sensor : 2MP CMOS
• Max. Resolution : 1920 (H) × 1080 (V)
• Scanning System : Progressive
• S/N Ratio : >65 dB
• Illumination Distance : 20 m (65.62 ft)
• Illuminator On/Off Control : Auto/Manual
• Illuminator Number : 2 (IR light)
• Lens Type : Fixed-focal
• Lens Mount : M12
• Focal Length : 2.8 mm; 3.6 mm; 6 mm
• Video Resolution : 1080p (1920 × 1080); 720p (1280 × 720); 960H (960 × 576/960 × 480)
• Day/Night : Auto (ICR)/Color/B/W
• BLC : BLC; HLC; DWDR
• Noise Reduction : 2D NR
• Video Output : Video output choices of CVI/TVI/AHD/CVBS by one BNC port

Power Features

• Power Supply : 12 VDC ± 30%
• Power Consumption : Max. 2.7 W (12 VDC, IR on)

Dimensions & Weight

• Dimensions : 149.3 mm × 69.8 mm × 69.8 mm (5.88" × 2.75" × 2.75")
• Net Weight : 0.14 kg (0.31 lb)
• Gross Weight : 0.17 kg (0.37 lb)
